제품 상세정보
원래 장소: 광동, 중국
브랜드 이름: LINK-PP
인증: ISO 9001,ISO 14001,UL,SGS,REACH168
모델 번호: 1-2007637-5
지불과 운송 용어
최소 주문 수량: 10/100/25K
가격: $0.11-$35
포장 세부 사항: 20/Tray
배달 시간: 주식
지불 조건: TT,NET30/60/90 일
공급 능력: 350K/Month
명세: |
1-2007637-5 |
상표: |
LINK-PP |
섬유 유형: |
싱글모드 유리 |
이미터: |
EML |
전압: |
3.15V~3.45V |
신청: |
일반 데이타 전송 |
연결관: |
SMF SC |
거치: |
, SFP Pluggable |
CE RoH: |
고분고분한 |
명세: |
1-2007637-5 |
상표: |
LINK-PP |
섬유 유형: |
싱글모드 유리 |
이미터: |
EML |
전압: |
3.15V~3.45V |
신청: |
일반 데이타 전송 |
연결관: |
SMF SC |
거치: |
, SFP Pluggable |
CE RoH: |
고분고분한 |
| Specifications: | 1-2007637-5 |
| LINK-PP Part Number: | LPXXXXXX |
| Product Class: | Fiber Optics |
| Product Family: | Optical Transceivers |
| Product Series: | SFP+ |
| Product Name: | SFP+ Optical Transceivers |
| Status Available: | Active |
| RoHS: | RoHS-6 Compliance |
|
Specifications:
|
|
|
Data Rate: |
1250 Mbps |
| Wavelength: | 1310nm |
| Maximun Distance: | 10000m |
| Fiber Type: | Singlemode Glass |
| Emitter: | EML |
| Voltage-Supply: | 3.15V~3.45V |
| Applications: | General Data Transfer |
| Connector Type: | SC |
| Mounting Type: | Pluggable,SFP |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Moisture Sensitivity Level(MSL): | 1(Unlimited) |
|
Feature Description:
|
● EPON ONU in MSA SFP Footprint
● Compliance with IEEE802.3ah1
● Optional CTC OAM Support, or DPoETM Support
● Built-in Digital Diagnostics Functions
● Single fiber Bi-Directional SC Receptacle
● Compatibility with EPON OLTs and CPE Equipment
|
Description:
|
● EPON Stick (SFP-ONU) provides a unique enhanced digital diagnostic monitoring interface which allows real-time access to a device’s operating parameters such as transceiver temperature, laser bias current, transmitted optical power,received optical power and transceiver supply voltage. It also defines a sophisticated system of alarms and warning flags which alerts end-users when certain operating
parameters are outside of a factory-set normal range.
● The SFP MSA defines a 256-byte memory map in EEPROM that is accessible over a 2-wire serial interface at the 8 bit address 1010000X (A0h). The digital diagnostic monitoring interface makes use of the 8 bit address 1010001X (A2h), A0h stores static information including product and vendor IDs while A2h contains real-time diagnostic data.
|
Applications:
|
● Providing Pluggable EPON ONU
● Interface for Ethernet Switches
● Wireless Backhaul Equipment
● Ethernet Demarcs
● Routers
● DSLAMs and other Customer Premises Equipment
