제품 상세정보
Place of Origin: China
브랜드 이름: LINK-PP
인증: ROHS,Reach
Model Number: 1-1840860-2
지불과 운송 용어
Minimum Order Quantity: 50pcs
가격: $0.09-$2.3
Packaging Details: Tape and Reel (1 Reel = 350pcs)
Delivery Time: Ships within 1-2 weeks
Payment Terms: TT, NET30/60/90 Days
Supply Ability: 6.5million-PCS/Month
Number of Channels/Ports: |
2x6 |
Mounting Style: |
Through Hole Mount |
PoE Rating: |
Non-PoE |
Data Rate: |
Gigabit |
Size: |
41.20 x 87.01 x 25.50mm |
Isolation Voltage: |
2250VDC |
Number of Channels/Ports: |
2x6 |
Mounting Style: |
Through Hole Mount |
PoE Rating: |
Non-PoE |
Data Rate: |
Gigabit |
Size: |
41.20 x 87.01 x 25.50mm |
Isolation Voltage: |
2250VDC |
| Items/Part Number | 1-1840860-2 MagJack |
|---|---|
| Turns Ratio | 1:1 All four pairs |
| Media side inductance | 350uH min @100KHz, 0.1VRMS, 8mA DC bias |
| Insertion Loss | - 1.1dB max from 1.0MHz to 100MHz |
| Return Loss |
- 18dB min from 1.0MHz to 40MHz; |
| Crosstalk Attenuation | - 35dB min from 1.0MHz to 40MHz; - 33-20LOG(f/50)dB min from 40.1MHz to 100MHz |
| Isolation Voltage | 2250VDC (max) for 60 seconds with a rise time of 500V/sec |
| Operating Temperature | 0°C - +70°C |
| Common Mode Rejection Ratio (CMRR) | - 30dB min from 1.0MHz to 100MHz |
• Blade servers or cards
• Network Interface cards
• Laptop computers
• Storage systems
• Mezzanine cards
