제품 상세정보
원래 장소: 중국 광동
브랜드 이름: LINK-PP
인증: UL,RoHS,Reach,ISO
모델 번호: J9151D
지불과 운송 용어
최소 주문 수량: 400/2000/10K/25K
가격: $3.2-$5
포장 세부 사항: t & r
배달 시간: 3 일 이내에 재고선
지불 조건: TT, NET30/60/90 일
공급 능력: 3kk/월
부품 번호: |
J9151D |
100% 크로스: |
LS-SM3110-10C |
시리즈: |
SFP+ 10G베이스 LR |
DOM / DDM: |
지원하다 |
핫 스왑 가능: |
예 |
애플리케이션: |
10GBASE-LR 이더넷 |
부품 번호: |
J9151D |
100% 크로스: |
LS-SM3110-10C |
시리즈: |
SFP+ 10G베이스 LR |
DOM / DDM: |
지원하다 |
핫 스왑 가능: |
예 |
애플리케이션: |
10GBASE-LR 이더넷 |
HPE Aruba J9151D 10G SFP+ LR Transceiver, 1310 nm, 10 km SMF, LC Duplex, DDM Supported — High-performance long-reach 10-Gigabit optical module for enterprise and data-center networks.
The HPE Aruba J9151D is a high-performance 10G SFP+ LR (Long-Reach) optical transceiver designed for enterprise switching, data-center interconnects, aggregation networks, and backbone links.
Operating at 1310 nm over single-mode fiber (SMF), the J9151D delivers up to 10 km transmission distance and supports full 10-Gigabit Ethernet performance.
Featuring Digital Optical Monitoring (DOM/DDM), low power consumption, and full compliance with SFP+ MSA and IEEE 802.3ae 10GBASE-LR standards, the J9151D ensures stable and reliable fiber connectivity for mission-critical deployments.
| Parameter | Specification |
|---|---|
| Model | HPE Aruba J9151D |
| Form Factor | SFP+ |
| Application | 10GBASE-LR Ethernet |
| Wavelength | 1310 nm |
| Fiber Type | Single-Mode Fiber (SMF) 9/125 µm |
| Connector |
Duplex LC |
| Parameter | Specification |
|---|---|
| Data Rate | 1.25–10.31 Gbps |
| Max Distance | 10 km over SMF |
| Transmitter Type | DFB Laser |
| Receiver Type | PIN Photodiode |
| Receiver Sensitivity | approx. −14 dBm (typical) |
| Optical Budget | approx. 6 dB (varies by vendor) |
| Parameter | Specification |
|---|---|
| Power Supply | +3.3 V |
| Operating Temperature | 0°C to 70°C (commercial) |
| Compliance | SFP+ MSA, IEEE 802.3ae, IEC-60825-1 laser safety, RoHS |
| DOM/DDM Support | Yes (temperature, voltage, Tx/Rx optical power) |
